The Price Displayed On The Product Does Not Include Tax And Shipping. The Shipping Cost Shown On The Page Is Not The Final Shipping Cost. Please Consult Customer Service For Shipping Costs Or Tax Rates Before Placing An Order.
LA SOUNDX

295W Beam Moving Head – Essential Edition

A compact professional beam moving head for clubs, live stages, rental productions and entertainment venues.

Compact power. Sharp beam.

The LA SOUNDX 295W Beam Moving Head combines a concentrated aerial beam with color, fixed gobo, frost, six-color and dual-prism effects for dynamic professional show programming.

Beam source
295W discharge lamp
Rated power
450W
DMX control
16CH
Movement
540° pan / 270° tilt

Layered beam effects

Fourteen colors plus white, thirteen fixed gobos plus open, frost, six-color effects and independently controlled prism layers support varied aerial looks.

Dual-prism engine

An 8-facet prism and honeycomb prism can be used independently or overlaid for wide multi-beam projection and energetic mid-air effects.

Professional control

DMX512, sound, automatic and master/slave modes combine with fine pan/tilt positioning, dual-motor focus and a reversible color display.

Technical specification

Verified from the supplied product brochure, operation manuals and fixture library.

Input voltage
AC 100-240V, 50/60Hz
Rated power
450W
Light source
295W discharge lamp
DMX channels
16CH
Operating modes
DMX512 / sound / auto / master-slave
Color wheel
14 colors + open white
Fixed gobos
13 patterns + open
Prism system
8-facet + honeycomb (8+16+24), overlay
Focus
Dual-motor high-definition focus
Frost
Integrated frost effect
Dimming
0-100% linear dimming
Pan / Tilt
540° / 270°, 1.2° fine adjustment
Display
1.8-inch color screen, 180° reversible
Protection
IP20, professional indoor use
Product size
30 x 26 x 51cm
Net / gross weight
12.1 / 14.1kg
Packing size
53.5 x 37.5 x 40.5cm
Housing
High-temperature plastic + alloy
LA SOUNDX 295W Beam Moving Head product detail 01 LA SOUNDX 295W Beam Moving Head product detail 02 LA SOUNDX 295W Beam Moving Head product detail 03 LA SOUNDX 295W Beam Moving Head product detail 04 LA SOUNDX 295W Beam Moving Head product detail 05 LA SOUNDX 295W Beam Moving Head product detail 06 LA SOUNDX 295W Beam Moving Head product detail 07 LA SOUNDX 295W Beam Moving Head product detail 08 LA SOUNDX 295W Beam Moving Head product detail 09 LA SOUNDX 295W Beam Moving Head product detail 10 LA SOUNDX 295W Beam Moving Head product detail 11 LA SOUNDX 295W Beam Moving Head product detail 12 LA SOUNDX 295W Beam Moving Head product detail 13 LA SOUNDX 295W Beam Moving Head product detail 14 LA SOUNDX 295W Beam Moving Head product detail 15 LA SOUNDX 295W Beam Moving Head product detail 16
