A2 10W RGB Laser

Product: A2-10W
Input voltage: AC 110-240 V, 50/60 Hz
Rated power: <= 120 W
Light source: 10 W RGB
DMX channels: 21CH delivered library mode
Control modes: DMX512, auto, sound active, master/slave and ILDA control
Product size: 230 x 230 x 180 mm; 270 mm including handle
Size / weight: 7.4 kg
Packing: 310 x 310 x 270 mm; 10 kg gross weight
RGB sources: R 638 nm / 3 W; G 520 nm / 3 W; B 445 nm / 4 W
Scanner: AT30K-40Kpps galvanometer scanner
Scan angle: +/-30 degrees (60-degree total)

Professional laser effects

A2-10W RGB Laser Light is designed for stages, venues, events and rental systems.

Rated power

<= 120 W

Light source

10 W RGB

DMX channels

21CH delivered library mode

Product size

230 x 230 x 180 mm; 270 mm including handle

Professional laser effects

A2-10W RGB Laser Light is designed for stages, venues, events and rental systems.

Flexible output platform

10 W RGB.

Core effect engine

10 W RGB / 21CH delivered library mode.

Technical specification

Verified from the supplied product brochure, operation manuals and fixture library. Unconfirmed source values remain clearly marked.

Product

A2-10W

Input voltage

AC 110-240 V, 50/60 Hz

Rated power

<= 120 W

Light source

10 W RGB

DMX channels

21CH delivered library mode

Control modes

DMX512, auto, sound active, master/slave and ILDA control

Product size

230 x 230 x 180 mm; 270 mm including handle

Size / weight

7.4 kg

Packing

310 x 310 x 270 mm; 10 kg gross weight

RGB sources

R 638 nm / 3 W; G 520 nm / 3 W; B 445 nm / 4 W

Scanner

AT30K-40Kpps galvanometer scanner

Scan angle

+/-30 degrees (60-degree total)

Videos / Product video
