LA-GSL8 PROloudspeaker Line arrays Large format 3-way line array loudspeaker
- Components LF: 2 x 14" + 2 x 10"; MF: 1 x 10"; HF: 3 x 1.4" exit compression driver with 3.4" coil
- Dispersion 80°
- SPLmax 150 dB
- Weight 80 kg / 176 lb
LA-GSL8 PROloudspeaker Line arrays Large format 3-way line array loudspeaker
Sale price $0.00
Regular price (/)
标题
Amplifier
The following specifications of power amplifiers can be used to drive AL90.
Recommended products
System data
Frequency response (-5 dB standard)45 Hz - 18 kHz
Frequency response (-5 dB CUT mode)70 Hz - 18 kHz
Max. sound pressure1with D80 150dBCabinets per
D80 (ArrayProcessing)2
Loudspeaker data
Nominal impedance front LF4ohms
Nominal impedance side LF/MF/HF4 ohms
Power handling capacity front LF (RMS/peak 10 ms)800/3200 W
Power handling capacity side LF/MF/HF (RMS/peak 10 ms)800/3200 W
Nominal dispersion angle (horizontal)80 °
Splay angle settings0 … 7° (1° increment)
Components2 x 14" front LF driver2 x 10" side LF driver1 x 10" MF driver3 x 1.4" exit compression driver with 3.4" coilPassive crossover network
Connections1 x NLT4 F
