K1 The Industry Benchmark 3-Way Active, Dual 15"
Max SPL 149 dB
Bandwidth 35 Hz- 20 KHz
Transducers LF : 2 x 15"
MF : 4 x 6.5"
HF : 3 x 3"
Weight 106 kg / 234 lb
Directivity H: 90°
V: 5°
标题
Electroacoustic specs22
3-way active
full-range WST® enclosure
quad-amplified by
LA12X
Usable bandwidth
(-10 dB) 35 Hz – 20 kHz ([K1])
Maximum SPL1 149 dB
([K1])
Nominal directivity
(-6 dB) Horizontal: 90° symmetric
vertical: dependent
upon the number of elements and the line source curvature
Transducers LF: 2 ×
15″ neodymium
MF: 4 × 6.5″
neodymium, direct-radiating
HF: 3× 3″ diaphragm
compression drivers
Acoustical load LF:
bass-reflex
MF: bass-reflex
HF: DOSC waveguide
Nominal impedance
LF: 2 × 8 Ω
MF: 8 Ω
HF: 8 Ω
1 Peak level
measured at 1 m under free field conditions using pink noise with crest factor
4 (preset specified in brackets).
Physical specs
Connectors 2 ×
8-point PA-COM
Rigging and
handling 4 handles integrated into the cabinet
inter-enclosure
angles: 0°, 0.5°, 1°, 1.5°, 2°, 2.5°, 3°, 4° or 5°
Weight (net) 106 kg
/ 234 lb
Cabinet Premium
grade Baltic birch plywood
high density
polyethylene
Front Coated steel
grill
acoustically
neutral 3D fabric
Rigging components
High grade steel with anti-corrosion coating
Finish Grey brown
RAL 8019
IP IP43
48 K1 24 K1 SB 12KARA II 24 KS 28
KARA II-Way Active, Dual 8"/K1 3-Way Active, Dual 12"
KS28 Subwoofer, Dual 18"/K1-SB High power Subwoofer dual 15''
