V1260 12 x 60W RGBW Moving Beam Bar

Name: V1260 12 x 60W RGBW Moving Beam Bar
Brand: LA SOUNDX
SKU: LSX-LIGHT-123
Price: 490.44 USD
Availability: InStock

Twelve moving heads Each optical cell has independent vertical movement and zoom for wave, fan and chase programming.

01

Twelve moving heads Each optical cell has independent vertical movement and zoom for wave, fan and chase programming.

Rated power: 800W
Light source: 12 x 60W LED, source notation 6065
DMX channels: 20CH fixture-library verified; 53/101/155/169/179CH manual-documented
Movement: 12 independent tilt heads; 220 degrees; 16-bit

Twelve moving heads Each optical cell has independent vertical movement and zoom for wave, fan and chase programming.

The supplied exact-product stills document uniform red, alternating red/green and full multicolor output.

A documented 2.8-31 degree beam and 5-55 degree field/spot range supports narrow beams through broad wash coverage.

Verified from the supplied product brochure, operation manuals and fixture library. Unconfirmed source values remain clearly marked.

Product: V1260 12 x 60W RGBW Moving Beam Bar
Input voltage: AC100-240V, 50/60Hz technical table; safety text separately states 90-240V
Rated power: 800W
Light source: 12 x 60W LED, source notation 6065
DMX channels: 20CH fixture-library verified; 53/101/155/169/179CH manual-documented
Beam angle: 2.8-31 degrees
Movement: 12 independent tilt heads; 220 degrees; 16-bit
Strobe: 1-25Hz
Dimming: 0-100%; gamma curves; 1.2-25kHz adjustment documented
Protection: IP22
Size / weight: 1000 x 139.76 x 295.5mm excluding feet; 25.5kg net
Packing: 113 x 34 x 19cm; 28kg gross; one unit
Electrical protection: Rated current, fuse value and fuse-holder location: TBC.
